Technical Features and Application Scenarios of the 2.4G Wireless Linkage Solution in Night Lights

I. Technical Advantages

🔹 Multi-Device Synchronized Control
Utilizes the 2.4G wireless protocol to enable signal forwarding between lights. When one light is triggered, other connected lights are automatically activated in sync. The linkage supports wall penetration within a clear, unobstructed distance of less than 10 meters.
Example: When the hallway night light is triggered, the bedroom and living room lights are also activated in a relay-style illumination sequence.

🔹 Low Power Consumption & High Stability
Built with an integrated 2.4G SoC (MCU + wireless module), the standby power consumption is as low as 50μA/h. When paired with a 2600mAh lithium battery, the device can operate for up to six months. It offers stronger anti-interference capabilities than infrared sensing, making it ideal for complex home environments.

🔹 Flexible Configuration Modes

• Group Control: Supports pre-configured independent channels (e.g., master bedroom/guest room) to prevent signal interference.

• Code Clearing & Re-Pairing: Quickly clear codes or rebind lights using a remote control to suit different room layouts.

• Multi-Mode Switching: Includes always-on, motion-sensing, timer modes (10/30 minutes), and night light mode.

II. Core Functionalities

💡 Dynamic Dimming & Color Adjustment

• 10-level stepless brightness adjustment

• Supports switching between warm and white light

• Four preset modes: Warm Light / White Light / Warm White / Night Light

• Remembers the last used setting for convenience

📱 Smart Interaction Extensions

• Mobile app control for adjusting color temperature, brightness, and scene modes

• Compatible with physical remotes for one-click switching between brightest mode and night light mode

• Supports layered lighting control (e.g., chandelier zoned control)

👤 Optimized Human Motion Detection

• 120° wide-angle detection (3m front / 2m side range)

• Lights stay on for 15 seconds after motion is detected

• Automatically activates in low light to avoid false triggers during the day

The appearance of the night light is made of anodized aluminum, with a suspended soft light shade design. It is suitable for lighting various areas such as bedside, kitchen, entrance, corridor, staircase, bedroom, etc. It is both beautiful and functional. The lights can be linked with each other, that is, in a dim environment, any night light will send a signal when it senses human movement, lighting up the other night lights. The night light can forward the signal, greatly increasing the linkage range.

With the dual linkage design, two signal channels can be preset between the master bedroom and the guest bedroom, which are allocated to the two rooms for use, independent of each other and without interfering with each other. The induction light uses 2.4G wireless connection, linkage sensing distance: straight line unobstructed distance <10m; light sensing distance: front <3m, 120° side <2m, light on for 15 seconds after sensing the human body, flexible through walls, free lighting.
